Rail transfer trolley

Rail transfer trolley can drive straight, along S-shaped, arc-shaped tracks, or on combined tracks. It is widely used in papermaking, metallurgy, coal, electromechanical, military and other industries. Rail transfer trolleys are classified into many more categories, such as low voltage rail transfer trolley , explosion-proof special rail transfer trolley , automated rail transfer trolley, RGV automated rail transfer trolley, high-temperature rail transfer trolley, etc.

Advantages: Simple structure; Safety and flexibility; Easy maintenance; Long service life; Anti-high temperature; Explosion-proof; Can be intelligent and robotizationCan be intelligent and robotization

Ps:Depending on your specific needs,our transfer carts/trolleys could be installed Various types of functions and devices.

Customizable Items

Technical Parameters Table Of KPX Battery Transfer Cart
Rated Load Capacity (t)		5	10	15	20	30	40	50	60	80	100	150	200
Table Size(mm)	Length	2000	2400	3000	3000	4000	4500	5000	5000	6000	6000	7000	8000
	Width	1300	1500	2000	2000	2200	2200	2500	2500	2500	2500	3000	3000
	Height	450	500	550	550	600	600	700	700	800	800	900	900
Ground Clearance (mm)		≥50
Wheelbase (mm)		1300	1600	2000	2000	2700	3000	3300	3300	4000	4000	4800	5500
Rail Inner Distance (mm)		900	1100	1435	1435	1435	1435	1650	1650	1650	1650	2000	2000
Operation Method		Remote Control & Hand Operate Pendant
Move Way		Forward/backwards, Turning (Customized), Vertical-Horizontal Crisscross Movement (Customized)
Running Speed (m/min)		25			20
Motor Type		Low-voltage alternating current (AC) motor / brushless direct current (DC) motor
Brake Mode		Electromagnetic Brake
Protective Measures		Audible and visual alarm lamp+ Emergency stop button+Limit switch+Laser obstacle avoidance sensor(Optional)+Anti-collision contact edge(Optional)
Wheel Quantity		4											8
Wheel Material		ZG55
Drive Wheel Diameter (mm)		Ф300	Ф300	Ф350	Ф350	Ф400	Ф400	Ф500	Ф500	Ф600	Ф600 Heavy Duty Wheel	Ф700 Heavy Duty Wheel	Ф600 Heavy Duty Wheel
Recommended Rail Type		P15	P18	P24	P24	P38	P38	P43	P43	QU70	QU70	QU100	QU100
Battery Capacity (kW·h)		4.8	7.2	8.6	8.6	10.5	14.4	15.8	18.7	21.6	28.8	36	57.6
Battery Type		Lead-Acid Battery
Battery Endurance		5h Customized As Needed
Battery Charging Time		≤7h
Battery Charger		AC220V/AC380V
Working Environment		Temperature: -10°c～40°c; Humidity: 20%～80%, No Condensation (Customized for high-temperature and explosion-proof environments)
Vehicle Body Color		Customized
Other Functions		Battery Power Display,Over Voltage, Under Voltage, Over Current Protection etc
Versione Automatica – RGV		Combined With An Automatic Positioning System, Signal Reception System, And Programmable System, The Rgv Realizes Automated Handling Functions. Customizable Rgv Carts Such As Mother-Child Carts (Ferry Carts), Vertical-Horizontal Moving Carts, And Curved Track Carts Can Be Provided.
Notes: 1) Other gauges, table sizes, and load tonnages can be customized according to user requirements. 2) This model of rail trolleys can be customized with special vehicles such as mother-child cars, curved track carts, vertical-horizontal moving carts, etc., to meet specific usage needs. 3) This model of rail trolleys can receive instructions from call boxes and host computers to achieve automated handling. 4) Battery type and operating time (battery endurance) can be customized to meet customer needs. 5) The product is subject to continuous improvement and upgrades; specifications in the table may change without prior notice.

Crane Manufacturing Factory Intelligent Steel Rail Transfer Trolley
50 Tons Explosion Proof Rail Transfer Cart
Explosion-Proof Special Rail Transfer Cart
Customized 20 tons Steel coil battery rail transfer trolley
Heavy Duty Industrial 10 Tons Rail Transfer Trolley
20 tons cable drum Rail transfer trolley
100 tons Industrial Rail Transfer trolley
Rail transfer trolley used in the production workshop
Rail transfer trolley turntable transfer car
30T truntable Rail transfer transport platform
coil Rail battery transfer trolley

Typical Application

Multi-device cooperation

In intelligent factories and automated workshops, transfer carts/trolleys must be highly intelligent or AGVizd, and can work with other equipment and operation platforms to realize intelligent manufacturing and fully automaed production. In response to such needs, Remarkable has designed and produced multifunctional transfer cart and multivehicle coordinated operation transfer cart. Various devices can be installed on the countertop of the multifunctional transfer cart and multivehicle coordinated operation transfer cart to fit the intelligent requirements and automated programs in customers' production processes.

Anti-high temperature & Explosion-proof

In industries such as metallurgy, coal, military, nuclear power, Chemical, sandblasting, spray painting, transfer carts/trolleys usually work in high-temperature conditions, and anti-high temperature & explosion-proof are necessary functions of transfer carts/trolleys. Coping with high temperature environment, Remarkable proposed the following solutions: using anintegral frame structure that is compressive, tensile, and anti-high temperature; installing high load bearing wheels and hot dip galvanizing grille plates with good heat dissipation performance. In order to make a cart/trolley has explosion-proof function, the electric box, wheels, car body and remote controller we have configured for it have reached explosion-proof level.

Complex and special environments

Sometimes, industrial materials need to be transported in complex and special environments, which asks more from transportation tools. Our steering wheel omnidirectional mobile trackless transfer carts and RGV automated rail transfer carts/trolleys (such as the ferry rail transfer trolley and the vertical and horizontal moving automated rail transfer trolley) can solve this kind of problem. The advantages "free and flexible driving in all directions and small turning radius" of the steering wheel omnidirectional mobile trackless transfer cart, the design of "the main vehicle and the sub-vehicle" of the rail ferry transfer trolley and the rail change function of the vertical and horizontal moving automated rail transfer trolley are specially designed for complex and special environments.

PS:In addition to the applications described above, Remarkable can solve many more industrial material handling problems. We are able to meet all your needs!

Application

Remarkable provides customized industrial handling solutions and various application material transport solutions to the world. To solve material handling problems for important customers in industries such as Aerospace industry, nuclear power, steel,shipyard,heavy industry, manufacturing, power and electrical, hydropower and wind power, petroleum, Chemical Industry, Automotive manufacturing, new energy, construction, high-speed railway bridges, metallurgy, coal, security and communication, scientific research institutions (universities), and animal husbandry. Remarkable transportation solutions are applicable to various industries around the world. Its products have been exported to the United States, Mexico, the Netherlands, Poland, Saudi Arabia, the Czech Republic, Italy, Switzerland, Türkiye, Singapore, Thailand and other countries.

Aerospace equipment

Nuclear Power

Shipyard

Power and Electrical

Automotive manufacturing

Buildings, high-speed railway bridges

Equipment manufacturing

Steel & Foundry

Chemical Industry

Oil & Natural Gas

New energy

Research institutions

Home appliance communication industry

Animal husbandry

Cooperative Customer

Faq

Frequently Asked Questions

Q: What Material To Handle?

A : ----------

Q: What’s The Transfer Car’s Load Capacity And Table Size You Need?

A : All Of Our Transfer Cars Are Made To Order, We Can Design It According To Your Requirements And Needs.

Q: Cart Traveling Type?

A : RailWheel

Q: Loading Capacity?

A : --------------Tons

Q: Platform Size?

A : ---------------Mm*-------------Mm

Q: Power Supply?

A : CableBus BarRailBatteryLow VoltageOther

Q: What Cargo Will The Car Transport?

A : Our Transfer Car Is Suitable For Steel Mill, Aluminum Plant, Metallurgical Industry, Mold Factory, Material Transfer Workshop, Shipyard, Crane Parts Transfer, Cable Coil Transfer, Precast Concrete Transfer, Ladle Transport And So On.

Q: Will The Car Move On The Cement Floor Or On The Track?

A : If It Moves On The Track, Have You Installed The Track?If It Moves On The Cement Floor, Is There Any Slope, Water Or Oil On The Floor?

Q: What’s The Car’s Working Time Per Day And Moving Distance In Single Direction?

A : We Can Suggest The Power Supply Mode For You According To Your Working Time And The Car’s Moving Distance.

Q: How Many Transfer Cars Do You Want?

A : We Don't Have A Minimum Order Limit, But We Can Give You A 5% Discount If You Buy More Than 3 Sets Of Cars.

Q: What Power Supply Mode Do You Prefer?

A : There Are Some Power Supply Modes For You Choosing, Such As Battery Power, Cable Reel Power, Cable Drum Power, Low Voltage Rail Power, Busbar Power And Diesel Engine Power.

Q: What Delivery Term Do You Prefer? FOB/CIF

A : If CIF, What’s The Destination Seaport?If FOB, We Usually Deliver The Car To Qingdao Port, But We Can Accept Your Designated Seaport.

Q: Price Term?

A : Ex-WorkFCAFOBCIF/CIPDDP/DDU

Q: What Term Of Payment Do You Accept?

A : Generally Speaking, We Accept 50%T/T Deposit In Advance,The Balance 50% Is Paid By T/T Before Dispatch. However, 30% T/T Deposit In Advance, The Balance 70% Is Paid By T/T Before Dispatch Also Can Be Accepted To Meet Your Demand In Order To Further Cooperation. Of Course, The L/C Also Is OK.

Q: How Long Is The Delivery Time?

A : About 45 Days, According To The Customer's Requirements To Complete The Delivery Time.

Q: How Many Certificates?

A : ISO9001、CE、SGS And So On.

Our products have certificates of CE, ISO9001, etc.

4P = Prediction + Pretreatment + Process + Performance

The FirstP

Prediction

At the very beginning of formulating a solution, our engineers will predict the faults that might occur during the equipment utilization relying on their rich experience, and avoid quality risks in advance.
The SecondP

Pretreatment of Material

Before getting inside the warehouse, all steel plates must be pretreated and testified to be qualified.
The ThirdP

Process Inspection

There is quality inspection in every process. The previous process can be allowed to enter the next one only if it is qualified. The whole process inspection records must be well preserved.
The FourthP

Performance Test

Before delivery, all the transfer carts/trolleys must undergo performance test, including load forward and backward, obstacle avoidance, omnidirectional mobile, slope climbing, lifting, wireless remote control, etc.
